IMT 10000 - 10000 30-foot Crane Recommended Spare Parts

16 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
10000 30-foot Crane Recommended Spare Parts
This parts list is intended to provide the user with a stock of parts sufficient to keep the unit
operating with the minimal down-time waiting for parts, but it does not indicate these items will
fail within a year. In addition, there may be parts failures not covered by this list. Parts not listed
are considered as not being Critical or Normal Wear items during the first year of operations.
BASE & MAST ASSEMBLY
73051919
HYDRAULIC MOTOR
1
72601949
CAP SCREW 0.50-13 X 1.25 SHZC
2
72601629
CAP SCREW .75-10 X 4.00 HEX HEAD GR8 Z
4
72601817
CAP SCREW .75-10 X 3.25 HEX HEAD GR8 Z
16
BOOM ASSEMBLY
60030336
WEAR PAD-RC
1
60030337
WEAR PAD-ROUND
2
60030422
WEAR PAD-ROUND
1
60030423
WEAR PAD-RC
4
60030424
CAP- ANTI-TWO BLOCK PIN
2
60030428
WEAR PAD-ROUND
4
60030425
WEAR PAD-ROUND
2
60030429
WEAR PAD- ANTI-TWO BLOCK BRACKET
2
ANTI-TWO-BLOCK ASSEMBLY
77041863
LIMIT SWITCH
1
CRANE & WINCH ASSEMBLY
52718741
PIN (effective through 05/22/13)
2
52723036
PIN (effective through 05/22/13)
1
60140915
PIN-TYPE NN 2.0 X 13.75
(effective from 05/22/13)
2
60140916
PIN-TYPE NN 2.0 X 9.5
(effective from 05/22/13)
1
70732882
HOOK, 5.9 TON
1
70580203
WIRE ROPE ASSEMBLY
1
60030255
SHEAVE
1
LOWER CYLINDER (51722956)
94399133
SEAL KIT
1
51723931 CYLINDER (PART OF 51723604 EXT. CYLINDER ASSEMBLY)
94399160
SEAL KIT
1
51723927 CYLINDER (PART OF 51723604 EXT. CYLINDER ASSEMBLY)
94399162
SEAL KIT
1
WINCH (71570825)
73534498
OIL RETAINER SEAL
1
73534499
OIL RETAINER SEAL
1
73534500
BALL BEARING
1
73540344
DUAL COUNTERBALANCE VALVE ASSEMBLY
1
73534501
BALL BEARING
1
VALVE BANK (73734727)
94399213
SEAL KIT, CONNECTION BLOCK
1
94399214
SEAL KIT, VALVE SECTIONS
1
77041898
SOLENOID, 12V
1
