IMT 10000 - Base & Mast Assembly, Truck Mount (99904925)

28 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
Base & Mast Assembly, Test Stand (99904925)
(See Parts List for Effectivity Dates)
NOTE: This base and mast assembly is shown as it if it were mounted on a test stand.
66
11
41
34
50
77
77
51
59
111
128
128
111
115
80
81
77
33
41
BOTTOM VIEW
67
67
65
65
1
1
1
2
2
3
2 4
3
6
7
6
7
NOTES (SEE REFERENCE NUMBER IN BOX):
1 TORQUE TO 280 FT-LB (38.7 KG-M)
2 USE RUST PREVENTATIVE ON SLIDE STOP, BEARING RACE, BOTTOM OF MAST AND TOP OF GEAR
BEARING.
3 APPLY BLUE THREAD LOCKER.
4 APPLY GEAR LUBE ON GEAR TEETH.
5 BASE AND MAST ASSEMBLY SHOWN AS MOUNTED ON THE TEST STAND. NOTE ORIENTATION OF
MOTOR. BOTTOM VIEW OF ROTATION ASSEMBLY.
6 PORT A
7 PORT B
