IMT 10000 User Manual

Chapter 4 Parts 27
99904925 BASE & MAST ON TEST STAND
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
1.
91723059
KIT-HARDWARE BASE & MAST
1
5.
91723584
HARDWARE KIT
(effective through 05/22/13)
1
6.
91723601
HYDRAULIC KIT
A/R
91725088
HYDRAULIC KIT
SINGLE PROPORTIONAL
A/R
11.
52722950
MAST WELDMENT
(effective through 05/22/13)
1
33.
60120138
SLIDE-ROTATION STOP
1
34.
60128849
GEAR GUARD
1
41.
70029595
THREADED PLUG
1.00-8
2
50.
71056577
GEAR ROTATOR
0.75 BOLTS
1
51.
76039295
GASKET
#50
1
59.
73051919
MOTOR-HYDRAULIC
1
64.
72060207
CAP SCREW
(effective through 02/14/13)
.75-10 X 3.00 HEX HEAD GR8 Z
#1
2
65.
72063116
WASHER
.75 N FLAT H ASTM F436 Z
#1
22
66.
72601629
CAP SCREW
.75-10 X 4.00 HEX HEAD GR8 Z
#1
4
67.
72601817
CAP SCREW
(effective through 02/14/13)
.75-10 X 3.25 HEX HEAD GR8 Z
#1
16
77.
70034382
CAP-GREASE
#5
6
80.
72053301
COUPLING
BLK .12
#5
1
81.
72053508
ZERK
NPT 0.12
#5
4
111.
72601949
CAP SCREW
.50-13 X 1.25 SOCKET HEAD
ZINC-COATED
#5
2
115.
51395121
HOSE
AA .13 X 13.5 0 OAL (2-2)
#6
1
128.
72533613
ADAPTER
M STR/M JIC 10 6
#6
2
REV G 20120815
