50 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
FLIP SHEAVE ASSEMBLY PARTS LIST (99904925)
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QTY
48.
70734762
TRANSMITTER-RADIO
REMOTE
(effective from 04/17/13)
GATED W/HORN
A/R
49.
70734750
RECEIVER-RADIO REMOTE
(effective from 04/17/13)
SINGLE PROPORTIONAL
A/R
70734763
RECEIVER-RADIO REMOTE
(effective from 04/17/13)
A/R
53.
71414205
PLATE-SINGLE SHEAVE
(20 #) .50 WIRE ROPE
1
55.
72034485
CLAMP-PLASTIC
1/4 " CABLE
9
58.
72661641
PIN-QUICK
5/16-2-1/16 ZINC YELLOW
1
60.
73734565
PIN-LOCK WITH HANDLE
1.00 X 3.50 WITH HAIRPIN
3
74.
72062194
NUT-STAINLESS STEEL
.25 -20 NYLOC
#4
2
75.
72063166
WASHER-FLAT
.25 R WRT 18 -8 .62 OD
STAINLESS STEEL
#4
2
76.
72601846
CAP SCREW
.25-20 X 1.25 HEX HEAD
STAINLESS STEEL
#4
2
77.
70034382
CAP-GREASE
#5
6
81.
72053508
ZERK
NPT 0.12
#5
4
82.
72060000
CAP SCREW
.25-20 X .50 HEX HEAD GR5 Z
#5
2
88.
72060147
CAP SCREW
.62-11 X 1.00 HEX HEAD GR5 Z
#5
1
91.
72060893
CAP SCREW
.38-16 X 3.25 HEX HEAD GR5 Z
#5
2
92.
72062000
NUT
.25-20 HEX
#5
3
94.
72062103
NUT
.38-16 HEX NYLOCK
#5
2
95.
72062104
NUT (effective from 04/12/13)
.25-20 HEX NYLOCK
#5
2
97.
72062106
NUT
10-24 HEX NYLOCK
#5
8
98.
72063001
WASHER
(effective from 02/28/13)
.25 FLAT
#5
9
99.
72063003
WASHER
(effective from 04/10/13)
.38 FLAT
#5
17
100.
72063010
WASHER
1.00 FLAT
#5
1
102.
72063049
WASHER
(effective from 02/28/13)
.25 LOCK
#5
6
113.
72661543
PIN-QUICK
#5
3
114.
72661694
BRIDLE RING
1-1/12 ID X 1/ 4-20
#5
3
135.
93725207
KIT-CABLE GUIDE
(effective from 04/12/13)
9500/14000
1
136.
70734176
HOOK-SWIVEL
(effective from 04/26/13)
WITH LATCH
1
147.
60030486
SPACER-A2B BRACKET
(effective from 04/17/13)
2
148.
60140935
GUIDE-CABLE WEAR (WIDE)
(effective from 04/12/13)
#135
1
149.
60140938
BRKT-CABLE GUIDE (WIDE)
(effective from 04/12/13)
#135
1
150.
72060006
CAP SCREW
(effective from 04/12/13)
0.25-20 X 1.5 HH GR5
#135
2
151.
72062104
NUT (effective from 04/12/13)
0.25-20 HEX NYLOCK
#135
2
REV G 20120815
