52 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
30.
60030429
WEAR PAD- ANTI-TWO BLOCK
BRACKET
(effective through 04/17/13)
2
31.
70034490
PLATE-ANGLE PLASTIC
3.5"
2
32.
60109337
PIN RETAINER PLATE
3.00 DIA
1
33.
60120138
SLIDE-ROTATION STOP
1
34.
60128849
GEAR GUARD
1
35.
60140028
CAP-LOWER BOOM
(effective through 04/12/13)
(WAS 60135667)
1
36.
60135668
CAP-FIRST STAGE
1
37.
60135669
PIN
1.2 5X 6.89 ( 6.46)
1
38.
52723623
HOOK HOLDER-WELDMENT
(effective through 05/22/13)
1
39.
60135833
RETAINER-1st STAGE
EXTENSION CYLINDER
2
40.
60136475
COVER-VALVE BANK
(effective through 03/05/13)
1
41.
70029595
THREADED PLUG
1.00-8
2
42.
70034517
SPLIT SHEAVE PROTECTOR
(effective through 05/22/13)
1
43.
70145121
COLLAR-SHAFT 2 PIECE
7/8 in.
1
44.
70399044
TAPE -REFLECTIVE RED/
SILVER
1.25 X108.00
2
45.
70399045
TAPE -REFLECTIVE RED/
SILVER
2.00 X108.00
2
46.
70580203
WIRE ROPE ASSEMBLY
0.44 (6X25 )X130 ft LH LAY
1
47.
70732882
HOOK-SWIVEL POS LOCK
(effective through 04/26/13)
5.9 TON
1
48.
70734559
TRANSMITTER-RADIO
REMOTE
(effective through 04/17/13)
1
49.
70734560
RECEIVER-RADIO REMOTE
(effective through 04/17/13)
1
50.
71056577
GEAR ROTATOR
0.75 BOLTS
1
51.
76039295
GASKET
#50
1
52.
71073035
HOOK-SWIVEL
(effective through 04/26/13)
5.0T W/LATCH
1
53.
71414205
PLATE-SINGLE SHEAVE
(20 #) .50 WIRE ROPE
1
54.
71570825
WINCH-PLANETARY
60.00 LB LINE PULL (A60)
1
55.
72034485
CLAMP-PLASTIC
1/4 " CABLE
9
56.
72063038
MACHINERY BUSHING
2.00 X14 GA NR
A/R
57.
72063039
MACHINERY BUSHING
2.00 X10 GA NR
A/R
58.
72661641
PIN-QUICK
5/16-2-1/16 ZINC YELLOW
1
59.
73051919
MOTOR-HYDRAULIC
1
60.
73734565
PIN-LOCK WITH HANDLE
1.00 X 3.50 WITH HAIRPIN
3
61.
73734727
VALVE BANK (WAS 73734635)
10 GPM
1
62.
77041863
SWITCH-LIMIT
DT04-4P CONN
1
63.
77441481
HARNESS-RADIO REMOTE
(WAS 77441426)
1
64.
72060207
CAP SCREW
(effective through 02/14/13)
.75-10 X 3.00 HEX HEAD GR8 Z
#1
2
65.
72063116
WASHER
.75 N FLAT H ASTM F436 Z
#1
22
