IMT 10000 User Manual

Chapter 4 Parts 53
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
66.
72601629
CAP SCREW
.75-10 X 4.00 HEX HEAD GR8 Z
#1
4
67.
72601817
CAP SCREW
(effective through 02/14/13)
.75-10 X 3.25 HEX HEAD GR8 Z
#1
16
68.
72062108
NUT
.50 -20 HEX CENTER LOCK
#2
4
69.
72063132
WASHER
.50 FLAT ASTM F436
#2
4
70.
72602061
STUD
(effective through 12/06/12)
.50-13(20)X2.5 NC(NF) GR8STL
#2
4
71.
72601797
WASHER-LOCK
8MM
#3
3
72.
72602065
WASHER-FLAT
M8
#3
3
73.
72602052
CAP SCREW
M8-1.25X 16 HEX HEAD Z
#3
3
74.
72062194
NUT-STAINLESS STEEL
.25 -20 NYLOC
#4
2
75.
72063166
WASHER-FLAT
.25 R WRT 18 -8 .62 OD
STAINLESS STEEL
#4
2
76.
72601846
CAP SCREW
.25-20 X 1.25 HEX HEAD
STAINLESS STEEL
#4
2
77.
70034382
CAP-GREASE
#5
6
78.
71413185
SPRING
.105 WIRE 0.75OD 2 .875 LG
#5
1
79.
72034479
PLUG-PLASTIC
.50-13 X .50 UNC-2B
#5
2
80.
72053301
COUPLING
BLK .12
#5
1
81.
72053508
ZERK
NPT 0.12
#5
4
82.
72060000
CAP SCREW
.25-20 X .50 HEX HEAD GR5 Z
#5
2
83.
72060002
CAP SCREW
(effective through 02/28/13)
.25-20 X .75 HEX HEAD GR5 Z
#5
4
84.
72060044
CAP SCREW
.38-16 X .75 HEX HEAD GR5 Z
#5
4
85.
72060064
CAP SCREW
(effective through 04/17/13)
.44-14 X 1.50 HEX HEAD GR5 Z
#5
4
86.
72060091
CAP SCREW
(effective through 05/22/13)
.50-13 X 1.00 HEX HEAD GR5 Z
#5
5
87.
72060093
CAP SCREW
.50-13 X 1.75 HEX HEAD GR5 Z
#5
12
88.
72060147
CAP SCREW
.62-11 X 1.00 HEX HEAD GR5 Z
#5
1
89.
72060206
CAP SCREW
.75-10 X 2.00 HEX HEAD GR8Z
#5
1
90.
72060639
SCREW-MACHINERY
10-24 X 1.50 ROUND HEAD
#5
2
91.
72060893
CAP SCREW
.38-16 X 3.25 HEX HEAD GR5 Z
#5
2
92.
72062000
NUT
.25-20 HEX
#5
3
93.
72062093
NUT
#8 -32 HEX ZINC
#5
2
94.
72062103
NUT
.38-16 HEX NYLOCK
#5
2
95.
72062104
NUT (effective through 04/12/13)
.25-20 HEX NYLOCK
#5
2
96.
72062105
NUT (effective through 04/17/13)
.44-14 HEX NYLOCK
#5
4
97.
72062106
NUT
10-24 HEX NYLOCK
#5
8
98.
72063001
WASHER
(effective through 02/28/13)
.25 FLAT
#5
9
99.
72063003
WASHER
(effective through 04/10/13)
.38 FLAT
#5
17
100.
72063010
WASHER
1.00 FLAT
#5
1
101.
72063035
M MACHINERY BUSHING
1.25 X10 GA NR
#5
2
102.
72063049
WASHER
(effective through 02/28/13)
.25 LOCK
#5
6
103.
72063051
WASHER
.38 LOCK
#5
4
