54 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
MODEL 10000 CRANE ASSEMBLY (99904925) PARTS LIST
ITEM
PART#
DESCRIPTION
DETAILS
KIT #
QTY
104.
72063053
WASHER
(effective through 05/22/13)
.50 LOCK
#5
17
105.
72063116
WASHER
FLAT .75 N H ASTM F436 Z
#5
1
106.
72063132
WASHER
.50 FLAT ASTM F436
#5
17
107.
72063271
WASHER
# 8 W FLAT ANSI B 27. 2Z
#5
2
108.
72066129
RETAINING RING-EXTERNAL
1.25 HD
#5
2
109.
72066136
RETAINING RING-EXTERNAL
(effective through 05/22/13)
2.00 HD
#5
3
110.
72601938
BOLT-EYE
# 8-32X 1.125
#5
1
111.
72601949
CAP SCREW
.50-13 X 1.25 SOCKET HEAD ZINC-
COATED
#5
2
112.
72602085
BOLT-SHOULDER
.38X 1.25
#5
1
113.
72661543
PIN-QUICK
#5
3
114.
72661694
BRIDLE RING
1-1/12 ID X 1/ 4-20
#5
3
115.
51395121
HOSE
AA .13 X 13.5 0 OAL (2-2)
#6
1
116.
72532355
ADAPTER
M STR/M JIC 6 6
#6
1
117.
72532356
ADAPTER
M STR/M JIC 8 6
#6
4
118.
72532357
ADAPTER
M STR/M JIC 6 8
#6
1
119.
72532358
ADAPTER
M STR/M JIC 8 8
#6
4
120.
72532359
ADAPTER
M STR/M JIC 10 8
#6
2
121.
72532361
ADAPTER
M STR/M JIC 8 10
#6
1
122.
72532670
ELBOW
M JIC/45/ F JIC 8 8
#6
1
123.
72532690
ELBOW
M JIC/90 /FJIC SW 4 4
#6
1
124.
72532700
ELBOW
M STR/90/ M JIC XL 6 6
#6
2
125.
72532792
ADAPTER
M STR/M JIC 8 4
#6
1
126.
72533490
ADAPTER
M BSPP/M JIC 4 4
#6
1
127.
72533583
ELBOW
M STR/45/ M JIC 8 6
#6
1
128.
72533613
ADAPTER
M STR/M JIC 10 6
#6
2
129.
72602075
CAP SCREW
(effective through 04/12/13)
.50-13 X 12.5 HHGR5Z
#135
1
130.
72062073
CAP SCREW
(effective through 04/12/13)
.50-13 X 11.5 HHGR5Z
#135
1
131.
72063005
WASHER
(effective through 04/12/13)
.50 FLAT
#135
2
132.
72062080
NUT (effective through 04/12/13)
.50-13 HEX NYLOCK
#135
2
133.
60140030
ROLLER-CABLE GUIDE
(effective through 04/12/13)
#135
2
134.
60140029
BRACKET-CABLE GUIDE
(effective through 04/12/13)
#135
1
135.
93724760
KIT-CABLE GUIDE
(effective through 04/12/13)
1
REV G 20120815
