IMT 10000 User Manual

Chapter 4 Parts 35
BOOM ASSEMBLY PARTS LIST (99904925)
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QTY
5.
91723584
HARDWARE KIT
(effective through 05/22/13)
1
9.
51723604
CYLINDER ASSEMBLY
2.50/ 1.50 2.75/1.75 204.0S 144.6
1
12.
52723022
WELDMENT-LOWER BOOM
(effective through 05/22/13)
7500/10000
1
13.
52723023
WELDMENT-1st STAGE EXT BOOM
(effective through 05/22/13)
7500/10000
1
14.
52723024
WELDMENT-2nd STAGE EXT BOOM
7500/10000
1
22.
60030336
WEAR PAD-RC
.19 X 6.00 X 6.00
1
23.
60030337
WEAR PAD-ROUND
2.00 DIA X 1.00 DIA X 1.188 LG
2
24.
60030421
WEAR PAD-RC
.25 X 6.00 X 6 .00
1
25.
60030422
WEAR PAD-ROUND
2.00 DIA X .50 DIA X 1.69 L
1
26.
60030423
WEAR PAD-RC
0.25 X 2.25 X 6.00L
4
27.
60030424
CAP- ANTI-TWO BLOCK PIN
(effective through 04/17/13)
2
29.
60030428
WEAR PAD-ROUND
2.0 0 DIA X .75 DIA X .72L
4
30.
60030429
WEAR PAD- ANTI-TWO BLOCK
BRACKET (effective through 04/17/13)
2
35.
60140028
CAP-LOWER BOOM
(effective through 04/12/13)
(WAS 60135667)
1
36.
60135668
CAP-FIRST STAGE
1
37.
60135669
PIN
1.2 5X 6.89 ( 6.46)
1
39.
60135833
RETAINER-1st STAGE EXTENSION
CYLINDER
2
44.
70399044
TAPE -REFLECTIVE RED/ SILVER
1.25 X108.00
2
45.
70399045
TAPE -REFLECTIVE RED/ SILVER
2.00 X108.00
2
87.
72060094
CAP SCREW
.50-13 X 1.75 HEX HEAD GR5 Z
#5
12
89.
72060206
CAP SCREW
.75-10 X 2.00 HEX HEAD GR8Z
#5
1
101.
72063035
M MACHINERY BUSHING
1.25 X10 GA NR
#5
2
104.
72063053
WASHER
(effective through 05/22/13)
.50 LOCK
#5
17
105.
72063116
WASHER
FLAT .75 N H ASTM F436 Z
#5
1
106.
72063132
WASHER
.50 FLAT ASTM F436
#5
17
108.
72066129
RETAINING RING-EXTERNAL
1.25 HD
#5
2
129.
72602075
CAP SCREW
(effective through 04/12/13)
.50-13 X 12.5 HHGR5Z
#135
1
130.
72062073
CAP SCREW
(effective through 04/12/13)
.50-13 X 11.5 HHGR5Z
#135
1
131.
72063005
WASHER
(effective through 04/12/13)
.50 FLAT
#135
2
132.
72062080
NUT (effective through 04/12/13)
.50-13 HEX NYLOCK
#135
2
133.
60140030
ROLLER-CABLE GUIDE
(effective through 04/12/13)
#135
2
134.
60140029
BRACKET-CABLE GUIDE
(effective through 04/12/13)
#135
1
135.
93724760
KIT-CABLE GUIDE
(effective through 04/12/13)
1
REV G 20120815
