44 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
99904925 CRANE & WINCH ASSEMBLY
ITEM
PART #
DESCRIPTION
DETAILS
KIT #
QTY
56.
72063038
MACHINERY BUSHING
2.00 X14 GA NR
A/R
57.
72063039
MACHINERY BUSHING
2.00 X10 GA NR
A/R
68.
72062108
NUT
.50 -20 HEX CENTER LOCK
#2
4
70.
72602061
STUD (effective through 12/06/12)
.50-13(20)X2.5 NC(NF) GR8STL
#2
4
79.
72034479
PLUG-PLASTIC
.50-13 X .50 UNC-2B
#5
2
83.
72060002
CAP SCREW
(effective through 02/28/13)
.25-20 X .75 HEX HEAD GR5 Z
#5
4
84.
72060044
CAP SCREW
.38-16 X .75 HEX HEAD GR5 Z
#5
4
86.
72060091
CAP SCREW
(effective through 05/22/13)
.50-13 X 1.00 HEX HEAD GR5 Z
#5
5
98.
72063001
WASHER
(effective through 02/28/13)
.25 FLAT
#5
9
99.
72063003
WASHER
(effective through 04/10/13)
.38 FLAT
#5
17
102.
72063049
WASHER
(effective through 02/28/13)
.25 LOCK
#5
6
103.
72063051
WASHER
.38 LOCK
#5
4
104.
72063053
WASHER (effective through
05/22/13)
.50 LOCK
#5
17
106.
72063132
WASHER
.50 FLAT ASTM F436
#5
17
109.
72066136
RETAINING RING-EXTERNAL
(effective through 05/22/13)
2.00 HD
#5
3
116.
72532355
ADAPTER
M STR/M JIC 6 6
#6
1
118.
72532357
ADAPTER
M STR/M JIC 6 8
#6
1
120.
72532359
ADAPTER
M STR/M JIC 10 8
#6
2
124.
72532700
ELBOW
M STR/90/ M JIC XL 6 6
#6
2
REV G 20120815
