IMT 10000 User Manual

66 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
4 TORQUE ROD BEARING TO 200-300 FT-LB (27.6 - 41.5 KG-M).
5 TORQUE PISTON NUT (#4) TO 412.3 FT-LB (57 KG-M).
6 TO LOCK THE ROD BEARING ON THE CYLINDER, DRILL A #26 HOLE 0.25-0.30" DEEP IN A SEAM
BETWEEN THE ROD BEARING AND THE CASE. INSTALL THE LOCKING SCREW (ITEM #9, SELF-
TAPPING #8-32 X 0.25" SET SCREW) IN THE HOLE UNTIL SEATED.
7 SEAL KIT 94399160 INCLUDES ALL SEALS FOR CYLINDER 51723931.
51723931 PARTS LIST
ITEM
PART #
DESCRIPTION
DETAILS
QUANTITY
1.
52724028
CASE
1
2.
71414724
PISTON ASSEMBLY
1
3.
52724029
ROD ASSEMBLY
1
4.
SELF-LOCKING NUT
1.00-14 UNF
1
5.
71414723
ROD BEARING ASSEMBLY
1
6.
LOCKING SCREW
1
7.
73050199
STROKE LIMITER
1
REF
94399160
SEAL KIT
1
NEW 20110407

IMT 10000 Specifications

General

Brand	IMT
Model	10000
Category	Construction Equipment
Language	English
