68 Model 10000 30-foot Parts & Specifications Manual Part # 99905185
NOTES:
1 SEE PART NUMBER AND REVISION STAMPED ON CYLINDER.
2 REPLACE ALL COMPONENTS OF THE SEAL KIT WHENEVER THE CYLINDER IS DISASSEMBLED TO
REDUCE DOWNTIME.
3 APPLY "LUBRIPLATE" NO. 630-2 MEDIUM-HEAVY, MULTI-PURPOSE LUBRICANT TO ALL PISTON, ROD
BEARING AND HOLDING VALVE SEALS.
4 TORQUE ROD BEARING TO 200-300 FT-LB (27.6 - 41.5 KG-M).
5 TORQUE PISTON 200-300 FT-LB (27.6 - 41.5 KG-M).
6 TO LOCK THE ROD BEARING ON THE CYLINDER, DRILL A #26 HOLE 0.25-0.30" DEEP IN A SEAM
BETWEEN THE ROD BEARING AND THE CASE. INSTALL THE LOCKING SCREW (ITEM #6, SELF-
TAPPING #8-32 X 0.25" SET SCREW) IN THE HOLE UNTIL SEATED.
7 SEAL KIT 94399162 INCLUDES ALL SEALS FOR CYLINDER 51723927.
