74 5020 Parts & Specifications Manual Part # 99901218
Wiring Chart (70733351)
LOCATOR CODE: P1 AMP: HOOD: 2-1102137-1
TERM: 4-1105051-1 CONN: 2-1103109-3 CAVITY PLUG: -
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A1 WHT 16 ROT CW J11B TO SPL L -
A2 WHT 16 EXT J12B TO SPL M -
A3 WHT 16 WIN J5B TO SPL D -
A4 WHT 16 WIN J14B TO SPL P -
A5 WHT 16 PROP VLV (+) TO SPL H -
A6 WHT 16 EXT J7B TO SPL F -
A7 WHT 16 ENG START TO P2 6
A8 WHT 16 RADIO GND TO SPL B -
A9 WHT 16 ENG SPEED TO P2 4
B1 - - - TO - -
B2 WHT 16 ROT CCW J8B TO SPL G -
B3 WHT 16 RADIO PWR TO SPL K -
B4 WHT 16 ENG KILL TO P2 2
B5 WHT 16 LOW DN P1 B5 TO SPL E -
B6 - - - TO - -
B7 WHT 16 LOW P1 B7 TO SPL N -
C1 WHT 16 PROP (-) TO SPL J -
C2 WHT 16 SOL PWR TO SPL R -
C3 WHT 16 COMPRESSOR TO SPL Q -
C4 WHT 16 WINSPD J16B TO P16 B
C5 - - - - - -
C6 - - - - - -
C7 - - - - - -
C8 - - - - - -
C9 - - - - - -
LOCATOR CODE: P2 DUETSCH DT04-8PA
TERM: 1060-16-0122 WEDGE: W8P CAVITY PLUG: 114017
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
1 WHT 16 SOL PWR TO SPL R -
2 WHT 16 ENG KILL TO P1 B4
3 WHT 16 RADIO GND TO SPL B -
4 WHT 16 ENG SPEED TO P1 A9
5 WHT 16 COMPRESSOR TO SPL Q -
6 WHT 16 ENG START TO P1 A7
7 WHT 16 RADIO POWER TO SPL K -
8 - - - TO - -
LOCATOR CODE: J5 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
