IMT 5020 Parts & Specifications

Chapter 4 Parts 75
Wiring Chart (70733351)
A WHT 16 J5A WINCH DN TO SPL B -
B WHT 16 J5B WINCH DN TO SPL D -
LOCATOR CODE: J9 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J9A ANTI-TWO TO SPL B -
B WHT 16 P10B TO J9B TO P10 B
LOCATOR CODE: P10 PACKARD: 12015792
TERM: 12124580 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 OPSI P10A TO R1 85
B WHT 16 P10B TO J9B TO J9 B
LOCATOR CODE: J11 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J11A ROT CW TO SPL B -
B WHT 16 J11B ROT CW TO SPL L -
LOCATOR CODE: J12 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J12A LOWER UP TO SPL B -
B WHT 16 J12B LOWER UP TO SPL N -
LOCATOR CODE: J13 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J13A EXT OUT TO SPL C -
B WHT 16 J13B EXT OUT TO SPL M -
LOCATOR CODE: J14 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J14A WINCH UP TO SPL C -
B WHT 16 J14B WINCH UP TO SPL P -
LOCATOR CODE: J15 PACKARD: 12010973
TERM: 12124582 SEAL: 12015359
CAVITY COLOR GA. PRINT LABEL TO CON-SPLC CAVITY
A WHT 16 J15A PROP (-) TO SPL J -
B WHT 16 J15B PROP (+) TO SPL H -
