8 Specifications and Model Selection
-
113
-
8
Parameter Name MD500 Model Functions Remark
CANopen
communication card
MD38CAN2 CANopen communication adapter card Available for all models
Profbus-DP
communication card
MD38DP2 Profbus-DP communication card
Available for models of
15 kW or above
User programmable
card
MD38PC1
User programmable extension card
Compatible with H1U-Series PLCs of Inovance
Available for models of
15 kW or above
Differential encoder
interface card
MD38PG1
Differential encoder resolver interface card, 5 V
power supply
Available for all models
Resolver interface card MD38PG4
For use with a resolver that has an excitation
frequency of 10 kHz. The card has a DB9
interface.
Available for all models
Open collector encoder
interface card
MD38PG5
Open collector encoder interface card, 1:1
frequency dividing, 15 V power supply
Available for all models
Open collector encoder
interface card
MD38PG5D
Open collector encoder interface card, optional
multiplying frequency division output, 15 V
power supply
Available for all models
Differential encoder
interface card
MD38PG6
Differential encoder resolver interface card, 5 V
power supply
Available for all models
Differential encoder
interface card
MD38PG6D
Differential encoder resolver interface card,
optional multiplying frequency division output,
5V power supply
Available for all models
MD38PGMD New multi-
function encoder card
MD38PGMD
Compatible of differential input, open-collector
input, and push-pull input
Supports differential output and open-collector
output
Compatible with A/B phase input interfaces of
often-used encoders and host computers.
Available for all models
External LED operating
panel
MD32NKE1
Connect to external LED display and operating
panel through RJ45
Available for all models
External LCD operating
panel
MDKE9 External LCD display and operating panel
Supports parameter
copy and download
Extension cable MDCAB
Standard: 8 cores
Can connect to MD32NKE1, MD32KC, and
MDCP
Standard length: 3 m
Through-hole mounting
model
MD500E-AZJ-A1T*
Can be used to mount the drive to the middle of
the cabinet
Each model has its
own bracket. For
details, see Table 3-1
Through-hole Mounting
Models in Chapter 3.
Cable support bracket MD500E-AZJ-A2T*
Can be used for secondary xing of power
cables and stable grounding of the shield
Each model has its
own bracket. For
details, see Table 3-5
Cable support bracket
models in Chapter 3.
