Inovance MD500 User Manual

8 Specifications and Model Selection
-
114
-
8
8.4 Cables, Breakers, and Contactors
1. Recommended Cables, Breakers, and Contactors
Table 8-7 Recommended Peripherals and Options
MD500 Model
Recommended
Input IEC Cable
(mm
2
)
<1>
Recommended
IEC Ground
Cable
(mm
2
)
Recommended
Output IE
Cable (mm
2
)
Terminal
width (mm)
Screw
Specication
Recommended
Fuse
Bussmann
Pass UL Certication
Recommended
Contactor
Recommended
Breaker
Rated
Current
(A)
MD500
Model
Rated Current
(A)
Rated
Current
(A)
Three-phase 380 to 480 V, 50/60 Hz
MD500T0.4GB 3 x 0.75 0.75 3 x 0.75 10.2 M4 5 FWP-5B 9 3
MD500T0.7GB 3 x 0.75 0.75 3 x 0.75 10.2 M4 5 FWP-5B 9 4
MD500T1.1GB 3 x 0.75 0.75 3 x 0.75 10.2 M4 10 FWP-10B 9 6
MD500T1.5GB 3 x 0.75 0.75 3 x 0.75 10.2 M4 10 FWP-10B 9 6
MD500T2.2GB 3 x 0.75 0.75 3 x 0.75 10.2 M4 10 FWP-10B 9 10
MD500T3.0GB 3 x 1 1 3 x 1 10.2 M4 15 FWP-15B 12 13
MD500T3.7GB 3 x 1.5 1.5 3 x 1.5 10.2 M4 20 FWP-20B 16 16
MD500T5.5GB 3 x 2.5 2.5 3 x 2.5 10.2 M4 30 FWP-30B 26 25
MD500T7.5GB 3 x 4 4 3 x 4 13.0 M5 40 FWP-40B 26 32
MD500T11GB 3 x 6 6 3 x 6 13.0 M5 60 FWP-60B 38 50
MD500T15GB 3 x 10 10 3 x 10 14.3 M5 70 FWH-70B 50 63
MD500T18.5G(B)(-T) 3 x 10 10 3 x 10 15.0 M6 80 FWH-80B 65 63
MD500T22G(B)(-T) 3 x 16 16 3 x 16 15.0 M6 100 FWH-100B 65 80
MD500T30G(B) 3 x 16 16 3 x 16 18.0 M6 100 FWH-100B 65 80
MD500T37G(B) 3 x 25 16 3 x 25 18.0 M6 125 FWH-125B 80 100
MD500T45G(B) 3 x 35 16 3 x 35 26.8 M8 150 FWH-150B 95 160
MD500T55G(B)
3 x 50 25 3 x 50 26.8 M8 200 FWH-200B 115 160
MD500T75G(B) 3 x 70 35 3 x 70 30.6 M12 250 FWH-250A 150 250
MD500T90G 3 x 95 50 3 x 95 30.6 M12 275 FWH-275A 170 250
MD500T110G
3 x 120 70 3 x 120 30.6 M12 325 FWH-325A 205 250
MD500T132G 3 x 150 95 3 x 150 * M12 400 FWH-400A 245 400
MD500T160G 3 x 185 95 3 x 185 * M12 500 FWH-500A 300 400
MD500T200G(-L) 2 x (3 x 95) 95 2 x (3 x 95) * M12 600 FWH-600A 410 500
MD500T220G(-L) 2 x (3 x 120) 120 2 x (3 x 120) * M12 700 FWH-700A 410 630
MD500T250G(-L) 2 x (3 x 120) 120 2 x (3 x 120) * M12 800 FWH-800A 475 630
MD500T280G(-L) 2 x (3 x 150) 150 2 x (3 x 150) * M12 800 FWH-800A 620 800
MD500T315G(-L)
2 x (3 x 185) 185 2 x (3 x 185) * M16 1000 170M5016 620 800
MD500T355G(-L)
2 x (3 x 185) 185 2 x (3 x 185) * M16 1000 170M5016 620 800
