8 Specications and Model Selection
8.1 Technical Specications of MD500 Series AC Drive
Table 8-1 Model and technical data
Item Specication
MD500TXXG(B) 0.4 0.7 1.1 1.5 2.2 3.0 3.7 5.5 7.5 11 15 18.5 22 30 37
Applicable motor
capacity
(kW)
0.4 0.75 1.1 1.5 2.2 3.0 3.7 5.5 7.5 11 15 18.5 22 30 37
Inputs
Rated input
current(A)
1.8 2.4 3.7 4.6 6.3 9.0 11.4 16.7 21.9 32.2 41.3 49.5 59 57 69
Outputs
Rated
output
current(A)
1.5 2.1 3.1 3.8 5.1 7.2 9.0 13.0 17.0 25.0 32.0 37 45 60 75
Outputs
Voltage
Three-phase 380 to 480 V (proportional to input voltage)
Max. output
frequency
500 Hz (editable through parameter)
Carrier
frequency
0.8 to 8.0 kHz (automatically adjusted according to the load characteristics)
Overload
capacity
150% for 60s
Power
supply
Rated
voltage
Rated
frequency
AC: Three-phase 380 to 480 V, 50/60 Hz
Allowed
voltage
uctuation
-15% to 10%, AC 323 to 528 V
Allowed
frequency
uctuation
±5%
Power
capacity
(kVA)
2 2.8 4.1 5 6.7 9.5 12 17.5 22.8 33.4 42.8 45 54 52 63
Thermal
esign
Thermal
design
power
(kW)
0.039 0.046 0.057 0.068 0.081 0.109 0.138 0.201 0.24 0.355 0.454 0.478 0.551 0.694 0.815
Air ow
(CFM)
- - - 9 9 9 20 24 30 40 42 51.9 57.4 118.5 118.5
Note
● MD500T18.5G(B)(-T) to MD500T22G(B)(-T) and MD500T18.5G(B) to MD500T22G(B) have the
same technical specications.
