Inovance MD500

Appendix C
-
181
-
Function
Code
Name Setting Range Default Change
AC-16 AO2 target voltage 1 -10.00V to 10.000V
Factory-
corrected
☆
AC-17 AO2 measured voltage 1 -10.00V to 10.000V
Factory-
corrected
☆
AC-18 AO2 target voltage 2 -10.00V to 10.000V
Factory-
corrected
☆
AC-19 AO2 measured voltage 2 -10.00V to 10.000V
Factory-
corrected
☆
C.2 Monitoring Parameters
Function
Code
Name Minimum Unit
Communication
Address
Group U0: Monitoring Parameters
U0-00 Running frequency 0.01Hz 7000H
U0-01 Frequency reference 0.01Hz 7001H
U0-02 Bus voltage 0.1V 7002H
U0-03 Output voltage 1V 7003H
U0-04 Output current 0.01A 7004H
U0-05 Output power 0.1kW 7005H
U0-06 Output torque 0.1% 7006H
U0-07 DI state 1 7007H
U0-08 DO state 1 7008H
U0-09 AI1 voltage 0.01V 7009H
U0-10 AI2 voltage (V)/current (mA) 0.01V/0.01mA 700AH
U0-11 AI3 voltage 0.01V 700BH
U0-12 Count value 1 700CH
U0-13 length value 1 700DH
U0-14 Load speed display 1 700EH
U0-15 PID reference 1 700FH
U0-16 PID feedback 1 7010H
U0-17 PLC stage 1 7011H
U0-18 Pulse reference 0.01kHz 7012H
U0-19 Feedback speed 0.01Hz 7013H
U0-20 Remaining running time 0.1Min 7014H
U0-21 AI1 voltage before correction 0.001V 7015H
U0-22 AI2 voltage (V)/ current (mA) before correction 0.001V/0.01mA 7016H
U0-23 AI3 voltage before correction 0.001V 7017H
U0-24 Linear speed 1m/Min 7018H
U0-25 Current power-on time 1Min 7019H
U0-26 Current running time 0.1Min 701AH
U0-27 Pulse reference 1Hz 701BH
U0-28 Communication reference 0.01% 701CH
U0-29 Encoder feedback speed 0.01Hz 701DH
U0-30 Main frequency reference 0.01Hz 701EH
U0-31 Auxiliary frequency reference 0.01Hz 701FH
U0-32 Viewing any register address value 1 7020H
U0-34 Motor temperature
1
°C 7022H
U0-35 Target torque 0.1% 7023H
U0-36 Resolver position 1 7024H
U0-37 Power factor angle 0.1° 7025H
U0-38 ABZ position 1 7026H
