Inovance MD500

3 Installation and Wiring
-
38
-
3
3. Remove and Ret of the Cover of Drives MD500T200G
(-L)
to MD500T450G
(-L)
Removal
Loosen six screws from the cover.
Hold the cover and pull it up in the arrow direction.
Retting
Locate and align the xing hook at the top of the cover.
Align the six screws to the xing holes on the cover.
Secure the six screws.
Figure 3-25 Remove and ret of the cover of drives
MD500T200G
(-L)
to MD500T450G
(-L)
