Integra DTR-10.5 User Manual

108
Listening Mode Setup —Continued
This sub-menu allows you to configure the audio effect
and playback options when you play a source in the
DTS listening mode.
a. LFE Level
This option allows you to set the bass level for the DTS
listening mode. The LFE level setting made here will be
applied to all of the DTS input signals. The available
settings are – ∞ dB, –20 dB, –10 dB, and 0 dB. The
option defaults to “0.” This option can also be set for
Zone 2.
b. SB Mode (5ch)
This option allows you to select the enhancement mode
for playback when you play a 5.1ch source as a 6.1 or
higher channel source through the DTR-10.5. The
surround back setting you select here will be applied to
the DTS input signal “*/2.”
• When the “(Speaker A) Surr Back” is set to “BTL for
Front,” “Bi-Amp for Front,” or “Not Used” in the
Speaker Configuration sub-menu, this option will not
be displayed.
NEO:6: Plays a 5.1ch source as a 6.1 or higher channel
source using the DTS NEO:6 mode.
Dolby EX: Plays a 5.1ch source as a 6.1 or higher
channel source using the Dolby Digital EX mode.
PLIIx Movie: Plays a 5.1ch source as a 6.1 or higher
channel source using the Dolby Pro Logic IIx Movie
mode.
• When you set the (Speaker A) Surr Back setting to
“Main A 1ch (SBL)” in the Speaker Configuration
sub-menu, you cannot select “PLIIx Movie.”
PLIIx Music: Plays a 5.1ch source as a 6.1 or higher
channel source using the Dolby Pro Logic IIx Music
mode.
Off: Plays an original 5.1ch source as it is.
c. Re-EQ
This option allows you to configure whether the Re-EQ
effect is applied or not. Use this effect when you do not
want to overemphasize the treble sound.
Off (Default): The effect is not applied.
On: Adjusts the soundtrack in which the treble is
overemphasized, so that the sound is optimized for
home theater.
d. Front Speaker
This option configures the front speakers to use when
playing the source in the DTS listening mode. Select the
speaker terminals to which the speakers you want to use
are connected. This setting can be made when the
“(Speaker B) Front L/R” is set to “Main A” in the
Speaker Configuration sub-menu.
• When the impedance setting for “Front L/R A” or
“Front L/R B” in the Speaker Impedance sub-menu is
set to “6 ohms” or “4 ohms,” the available options will
be “A” and “B.”
A (Default): Outputs the source from the speakers
connected to the FRONT L/R SPEAKERS A terminals.
B: Outputs the source from the speakers connected to
the FRONT L/R SPEAKERS B terminals.
A+B: Outputs the source from the speakers connected
to the FRONT L/R SPEAKERS A and FRONT L/R
SPEAKERS B terminals. Note that this option is not
available when the front speakers are in Bi-amp or in
BTL configuration.
e. Center Speaker
This option configures the center speaker to use when
playing the source in the DTS listening mode. Select the
speaker terminal to which the speaker you want to use is
connected. This setting can be made when the “(Speaker B)
Center” is set to “Main A” in the Speaker Configuration
sub-menu.
• When the impedance setting for “Center A” or
“Center B” in the Speaker Impedance sub-menu is set
to “6 ohms” or “4 ohms,” the available options will be
“A” and “B.”
A (Default): Outputs the source from the speaker
connected to the CENTER SPEAKERS A terminal.
B: Outputs the source from the speaker connected to the
CENTER SPEAKERS B terminal.
A+B: Outputs the source from the speakers connected
to the CENTER SPEAKERS A and CENTER
SPEAKERS B terminals.
f. Surr L/R Sp
This option configures the surround speakers to use
when playing the source in the DTS listening mode.
Select the speaker terminals to which the speakers you
want to use are connected. This setting can be made
when the “(Speaker B) Surr L/R” is set to “Main A” in
the Speaker Configuration sub-menu.
• When the impedance setting for “Surr L/R A” or “Surr
L/R B” in the Speaker Impedance sub-menu is set to
“6 ohms” or “4 ohms,” the available options will be
“A“ and “B.”
A (Default): Outputs the source from the speakers
connected to the SURR L/R SPEAKERS A terminals.
B: Outputs the source from the speakers connected to
the SURR L/R SPEAKERS B terminals.
A+B: Outputs the source from the speakers connected
to the SURR L/R SPEAKERS A and SURR L/R
SPEAKERS B terminals.
DTS Setup Sub-menu

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
