88
Speaker/Output Setup
The DTR-10.5 provides a wide range of variations in speaker connections and speaker settings, so you have to specify
speaker settings according to conditions of each variation. For proper selection of an AV device connected at switching
of the input type, you also need to allocate “audio output” and “video output” to each input type. If this allocation is
incorrect, the desired component will not play a selected input source.
Please setup correctly by referring to the information you wrote down in the Your System Settings booklet.
Specify the rooms where you want to use speakers
connected to the SPEAKERS A terminal and the
SPEAKERS B terminal. Specify according to settings
for main room A.
Note:
Basically, a speaker set with the maximum number of
speakers should be connected to the SPEAKERS A
terminals and configured for main room A (Main A).
When either the center, surround, or surround back
speakers are not connected to the SPEAKERS A
terminals, or any of these speakers is set to “Not Used”
in the Speaker A settings, you cannot perform the
settings for the corresponding speakers connected to the
SPEAKERS B terminals and those speakers connected
to the SPEAKERS B terminals cannot be used.
(Speaker A) Front L/R
The setting of the front speakers is initially fixed to
Main A.
Always install speakers connected to FRONT L/R of
SPEAKERS A in main room A.
(Speaker A) Center, Surr L/R
Main A (default):
Select this when using the center
speaker and/or surround speakers in main room A.
Not Used:
Select this when not using a center speaker
or surround speakers.
(Speaker A) Surr Back
Main A 2ch (default):
If Surr L/R is set to “Main A,”
you can select this item. Select this when connecting
and using two surround back speakers in main room A.
Main A 1ch (SBL):
If Surr L/R is set to “Main A,” you
can select this item. Select this when connecting and
using a surround back speaker in main room A.
BTL for Front:
Select this when using the front
speaker in main room A by connecting the surround
back channel to the speaker via BTL (See page 29).
Bi-Amp for Front:
Select this when using the front
speaker in main room A by connecting the front channel
and the surround back channel to the speaker via Bi-
Amp (See page 29).
Not Used:
Select this when not using surround back
speakers.
Note:
If “Not Used” is selected for Surr L/R, this item defaults
to “Not Used.”
(Speaker A) Subwoofer
Main A (default):
Select this when using a subwoofer
in the main room A.
Not Used:
Select this when not using a subwoofer in
the main room A.
(Speaker B) Front L/R
Main A:
Select this when using in main room A.
Main B:
Select this when using in main room B.
Not Used (default):
Select this when not using.
(Speaker B) Center
Main A:
Select this when using in main room A.
Main B:
Select this when using in main room B. This
setting can only be made when you set the “(Speaker B)
Front L/R” setting to “Main B.”
Not Used (default):
Select this when not using.
(Speaker B) Surr L/R
Main A:
Select this when using in main room A.
Main B:
Select this when using in main room B. This
setting can only be made when you set the “(Speaker B)
Front L/R” setting to “Main B.”
Not Used
(default):
Select this when not using.
(Speaker B) Surr Back
Main A 2ch:
Select this when connecting and using two
surround back speakers in main room A.
Main A 1ch (SBL):
Select this when connecting and
using a surround back speaker in main room A.
Main B 2ch:
If (Speaker B) Front L/R and Surr L/R are
both set to “Main B,” you can select this item. Select
this when connecting and using two surround back
speakers in main room B.
Main B 1ch (SBL):
If (Speaker B) Front L/R and Surr
L/R are both set to “Main B,” you can select this item.
Select this when connecting and using a surround back
speaker in main room B.
Powered Zone 2:
Select this when using in Zone 2.
• If (Speaker A) Surr Back is set to “BTL for Front” or
“Bi-Amp for Front,” this item is not displayed
(Because, if “Powered Zone 2” is set, BTL
connection and/or Bi-Amp connection are disabled).
BTL for Front:
This setting can be made only when
you set the “(Speaker B) Front L/R” setting to “Main A”
or “Main B.” Select this when using the front speaker in
main room B by connecting the surround back channel
to the speaker via BTL (See page 29).
Speaker Configuration Sub-menu
