71
Operations
Recording a Source
—Continued
You can add audio signals from a source to a video of
another source to make your own custom video record-
ings. Below is an example of recording audio signals
from a CD player connected to the DIGITAL IN OPTI-
CAL 2 jack and the video from a video camera con-
nected to VIDEO IN 3 onto a video cassette tape on a
VCR connected to VIDEO OUT 2.
Operate this function in the main room.
3
Press the [Rec/Zone 3] button, and within
3 seconds, select the source to be
recorded with the [Control/Tuning] dial.
Pressing the [Rec/Zone 3] button makes the
[Standby] indicator blink for 3 seconds. Select
the target sources while the indicator is blinking.
The name of the source to be recorded is indi-
cated in the display window. Audio/video record-
ing is enabled on the component for which “Rec
Out” was specified in step 2.
4
Prepare the component for audio/video
recording (recorder side).
5
Start audio/video recording.
You cannot listen to a broadcast from one station
while recording a broadcast from another station.
Recording the Video from One Source
and the Audio from Another Source
1
Turn on the power supply to the DTR-10.5
in Main A or Main B mode.
2
Check connections and settings to the
recording component.
Refer to steps 2 and 3 in “Recording Audio/Video
While Playing” on page 70.
3
Press the [CD] input source button.
4
Press the [Setup] button to display Main
menu, and turn the [Select/Preset] dial to
select Input Setup.
After selecting “Input Setup,” press the [Enter]
button.
To carry out steps 3-6 on the remote controller, fol-
low the procedures described on page 86.
5
Turn the [Select/Preset] dial to select
Video Assign, and press the [Enter] but-
ton.
6
Turn the [Select/Preset] dial to select
Composite Video, and set it to 3 with
the [Control/Tuning] dial.
After setting to “3,” press the [Setup] button.
7
Insert a CD in the CD player and insert a
tape in the video camera connected to the
VIDEO IN 3 jacks.
8
Insert a tape in the VCR connected to the
VIDEO OUT 2 jacks.
9
Press the [Rec/Zone 3] button, and within
3 seconds, select Rec Sel:CD with the
[Control/Tuning] dial.
Now, the CD player has been selected as the audio
input source, and VIDEO 3 as the video input
source.
10
Start recording on the VCR, and start play-
ing on the CD player and the video cam-
era.
Playback starts on the component selected in
steps 3-6.
Note:
Switching the source during audio/video record-
ing will record the source newly selected.
