Integra DTR-10.5 User Manual

110
Listening Mode Setup —Continued
e. Center Speaker
This option configures the center speaker to use when
playing the source in the AAC listening mode. Select
the speaker terminal to which the speaker you want to
use is connected. This setting can be made when the
“(Speaker B) Center” is set to “Main A” in the Speaker
Configuration sub-menu.
• When the impedance setting for “Center A” or
“Center B” in the Speaker Impedance sub-menu is set
to “6 ohms” or “4 ohms,” the available options will be
“A” and “B.”
A (Default): Outputs the source from the speaker
connected to the CENTER SPEAKERS A terminal.
B: Outputs the source from the speaker connected to the
CENTER SPEAKERS B terminal.
A+B: Outputs the source from the speakers connected
to the CENTER SPEAKERS A and CENTER
SPEAKERS B terminals.
f. Surr L/R Sp
This option configures the surround speakers to use
when playing the source in the AAC listening mode.
Select the speaker terminals to which the speakers you
want to use are connected. This setting can be made
when the “(Speaker B) Surr L/R” is set to “Main A” in
the Speaker Configuration sub-menu.
• When the impedance setting for “Surr L/R A” or “Surr
L/R B” in the Speaker Impedance sub-menu is set to
“6 ohms” or “4 ohms,” the available options will be
“A” and “B.”
A (Default): Outputs the source from the speakers
connected to the SURR L/R SPEAKERS A terminals.
B: Outputs the source from the speakers connected to
the SURR L/R SPEAKERS B terminals.
A+B: Outputs the source from the speakers connected
to the SURR L/R SPEAKERS A and SURR L/R
SPEAKERS B terminals.
g. Surr Bk Speaker
This option configures the surround back speakers to
use when playing the source in the AAC listening mode.
Select the speaker terminals to which the speakers you
want to use are connected. This setting can be made
when the “(Speaker B) Surr Back” is set to “Main A” in
the Speaker Configuration sub-menu. However, when
the “(Speaker A) Surr Back” is set to “BTL for Front,”
“Bi-Amp for Front,” or “Not Used,” this setting will not
be displayed.
• When the impedance setting for “Surr L/R A” or “Surr
L/R B” in the Speaker Impedance sub-menu is set to
“6 ohms” or “4 ohms,” the available options will be
“A” and B.”
• When the settings for “(Speaker A) Surr Back” and
“(Speaker B) Surr Back” in the Speaker
Configuration sub-menu differ, the available options
will be “A” and “B.”
A (Default): Outputs the source from the speakers connected
to the SURR BACK L/R SPEAKERS A terminals.
B: Outputs the source from the speakers connected to
the SURR BACK L/R SPEAKERS B terminals.
A+B: Outputs the source from the speakers connected
to the SURR BACK L/R SPEAKERS A and SURR
BACK L/R SPEAKERS B terminals.
h. Subwoofer
This option configures the subwoofer to use when
playing the source in the AAC listening mode. Select
the terminal to which the subwoofer you want to use is
connected. This setting can be made when the
“(Speaker A) Subwoofer” is set to an option other than
“Not Used” in the Speaker Configuration sub-menu.
However, when the “(Speaker B) Subwoofer” is set to
an option other than “Main A” in the Speaker
Configuration sub-menu, the available options will be
“A” or “Not Used.”
A (Default): Outputs the source only from the
subwoofer connected to the SUBWOOFER PRE OUT
A terminal.
B: Outputs the source only from the subwoofer
connected to the SUBWOOFER PRE OUT B terminal.
A+B: Outputs the source from the subwoofers
connected to the SUBWOOFER PRE OUT A and
SUBWOOFER PRE OUT B terminals.
Not Used: No subwoofers are used for playback.
This sub-menu allows you to configure the audio effect
and playback options when you play a 2ch input source
in the Dolby Pro Logic IIx or DTS NEO:6 listening
modes. This setting can be made when the “(Speaker A)
Center” or “(Speaker A) Surr Back” setting is set to an
option other than “Not Used” in the Speaker
Configuration sub-menu.
• When the “(Speaker A) Surr Back” is set to “BTL for
Front,” “Bi-Amp for Front” or “Not Used,” the PLII
mode will be used instead of the PLIIx mode.
a. Surr Mode (2ch)
Selects the enhancement mode for playback when you
play a 2ch source as a 6.1 or higher channel source
through the DTR-10.5. The surround mode setting you
select here will be applied to the Analog/PCM and D.F.
2ch input signals.
• The option “NEO:6 Music” will be available when the
(Speaker A) Surr Back setting is set to “Main A” in the
Speaker Configuration sub-menu.
PLIIx Movie (Default): Plays a 2ch source as a 6.1 or
higher channel source using the Dolby Pro Logic IIx
Movie mode.
PLIIx Music: Plays a 2ch source as a 6.1 or higher
channel source using the Dolby Pro Logic IIx Music
mode.
Dolby Pro Logic IIx/DTS NEO:6 (2ch
Input only) Setup Sub-menu

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
