Integra DTR-10.5 User Manual

118
Audio Adjust
You can adjust bass, mid, and treble notes for each
speaker set.
• For any speaker set to “Not Used” in the Speaker
Configuration sub-menu, no associated setting item is
displayed.
Front Bass
Option for adjusting bass notes from front L/R
speakers. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
This option can also be set for Zone 2.
Front Mid
Option for adjusting mid notes from front L/R speakers.
Specify at 1 dB intervals in a range from –12 dB to
+12 dB. The default is “0.”
This option can also be set for Zone 2.
Front Treble
Option for adjusting treble notes from front L/R
speakers. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
This option can also be set for Zone 2.
Center Bass
Option for adjusting bass notes from the center speaker.
Specify at 1 dB intervals in a range from –12 dB to
+12 dB. The default is “0.”
Center Mid
Option for adjusting mid notes from the center speaker.
Specify at 1 dB intervals in a range from –12 dB to
+12 dB. The default is “0.”
Center Treble
Option for adjusting treble notes from the center
speaker. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
Surr L/R Bass
Option for adjusting bass notes from surround L/R
speakers. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
Surr L/R Mid
Option for adjusting mid notes from surround L/R
speakers. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
Surr L/R Treble
Option for adjusting treble notes from surround L/R
speakers. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
Surr Bk Bass
Option for adjusting bass notes from the surround back
speaker. Specify at 1 dB intervals in a range from –12
dB to +12 dB. The default is “0.”
• If “Surr Back” is set to “BTL for Front” or “Bi-Amp
for Front” on the Speaker Configuration sub-menu,
this item is not displayed.
Surr Bk Mid
Option for adjusting mid notes from the surround back
speaker. Specify at 1 dB intervals in a range from –12
dB to +12 dB. The default is “0.”
• If “Surr Back” is set to “BTL for Front” and “Bi-Amp
for Front” on the Speaker Configuration sub-menu,
this item is not displayed.
Surr Bk Treble
Option for adjusting treble notes from the surround
back speaker. Specify at 1 dB intervals in a range from
–12 dB to +12 dB. The default is “0.”
• If “Surr Back” is set to “BTL for Front” or “Bi-Amp
for Front” on the Speaker Configuration sub-menu,
this item is not displayed.
Subwoofer Bass
Option for adjusting bass notes from the subwoofer.
Specify at 1 dB intervals in a range from –12 dB to
+12 dB. The default is “0.”
Tone Control Sub-menu

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
