Integra DTR-10.5 User Manual

93
Setup Menu
Input Setup
Items described here are set when you press the input source buttons.
The DTR-10.5 is equipped with several types of jacks in addition to the standard audio and video jacks, and multiple jacks
are provided for each type. You may freely assign input sources such as CD, PHONO, TUNER, TAPE 1, TAPE 2, and
VIDEO 1-7 to these jacks.
Moreover, you can preset a listening mode, specify names for display, adjust audio delays, correct the difference in the
volume level from other input sources, and set the 12V trigger.
In particular, please be careful when setting the input jacks. Please properly specify settings for correct selection of
pictures and audio to be played by referring to the information you wrote down in the Your System Settings booklet.
In the case of NET AUDIO, you can specify settings for the server (See page 95).
Settings defaults are as follows:
Note: Defaults may differ depending on your region or option board in use.
OSD Indication Audio Assign Video Assign
Analog Audio Multichannel Digital Audio i.LINK Composite
Video
S-Video Component
Video
HDMI
Name of Terminal
to be Set
AUDIO IN MULTI-CH
IN
DIGITAL IN iLINK VIDEO IN S VIDEO IN
COMPONENT
VIDEO IN
HDMI IN
NET AUDIO No No No No Last Last Last Last
CD 1 2 Opt 2 No Last Last Last Last
PHONO Phono No No No Last Last Last Last
TUNER No No No No Last Last Last Last
TAPE 1 2 No Opt 3 No Last Last Last Last
TAPE 2 3 No Coax 1 No Last Last Last Last
DVD 4 1 Opt 1 No 1 1 RCA 1 HDMI 1
VIDEO 1 5 No Coax 2 No 2 2 RCA 2 HDMI 2
VIDEO 2 6 No Coax 3 No 3 3 RCA 3 Video
VIDEO 3 7 No Opt 4 No 4 4 RCA 4/BNC Video
VIDEO 4 8 No Opt 5 No 5 No No Video
VIDEO 5 9 No Coax 4 No 6 No No Video
VIDEO 6 No No Coax 5 No No 5 No Video
VIDEO 7 Front No Front Opt No Front Front No Video
Input Selector

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
