Installation and Connections
Connecting AV Components
—Continued
• When connecting a DVD player to the DTR-10.5, make connections for video and audio signals using digital and
analog terminals. Before making connections, refer to pages 32 and 33 for correct connections.
• When you want to perform analog recording of the audio signal from a DVD player or operate your -compatible
Integra products via connections with the DTR-10.5, you have to make analog audio signal connections. Con-
nect the audio output terminals on the DVD player to the AUDIO IN terminals on the DTR-10.5 using analog audio
cables (RCA/phono).
• This section shows the connection example when you use the default settings of the DTR-10.5. However, you can
connect a DVD player to other terminals within the same terminal section on the DTR-10.5. In such case, remember
to configure the audio input assignment in the Audio Assign sub-menu (See page 94) and the video input assignment
in the Video Assign sub-menu (See page 95).
• For a model without a HDMI terminal, when you connect a DVD player to the COMPONENT terminals, be sure to
use the COMPONENT terminal to connect a TV or projector.
*For more information on the HDMI interface, see page 45.
*For more information on the i.LINK (AUDIO) interface, see page 42.
Connecting a DVD Player
