Integra DTR-10.5 User Manual

87
Setup Menu
Hardware Setup
In this section, you will perform the initial settings for the following scenarios.
• When you want to change the DTR-10.5’s remote control ID.
• When you want to fix the TV Format setting to PAL or NTSC.
• When you want to fix the AM Frequency Step setting to 9 kHz or 10 kHz.
Remote ID
This section explains how to change the DTR-10.5’s
remote control ID. You may need to change this if the
DTR-10.5’s remote controller interferes with other
Integra/Onkyo components located in the same room.
You can select 1, 2, or 3 for remote control ID.
If you change the DTR-10.5’s remote control ID, be
sure to select the same ID on the remote controller (See
page 142). The default ID for both the DTR-10.5 and
remote controller is 1.
Note:
It is recommended that you perform setup using the
[Setup]/[Select/Preset]/[Control/Tuning]/[Exit] buttons
of the DTR-10.5’s front panel.
If the remote controller is used for setup, signals from
the remote controller will not be received just after the
remote control ID settings have been changed (See
“Changing the Remote Controller’s Control ID” on
page 142 to change the remote control ID on the remote
controller).
TV Format (Australian model only)
The settings in the TV Format sub-menu can be
configured for Main B and Zone 2 as well as for Main A.
When you want to reconfigure the settings to conform
to the television format used in the area where you use
the DTR-10.5, use this sub-menu so that no time is
wasted on detection.
Auto: This is the default setting. When you leave this
setting unchanged, the television format is detected and
automatically set by the DTR-10.5.
PAL: Use this setting when you know the television
format is PAL.
NTSC: Use this setting when you know the television
format is NTSC.
Frequency Step
The setting in this sub-menu determines the incremental
or decremental amount when adjusting the AM tuner
frequency. The initial setting is 9 kHz, and this only
needs to be changed if you are using the DTR-10.5 in a
10 kHz region.
9 kHz: Select if 9 kHz increments are used in your area.
10 kHz: Select if 10 kHz increments are used in your
area.
Remote Control Setup Sub-menu
TV Format Sub-menu
AM Frequency Setup Sub-menu
(Australian Models Only)

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
