142
Other Settings for the Remote Controller
—Continued
This section explains how to change the remote control-
lers ID. You may need to change this if the DTR-10.5s
remote controller interferes with other Integra/Onkyo
components located in the same room.
Note:
If you change the remote controllers ID, be sure to
select the same ID on the DTR-10.5. For details on set-
ting up the DTR-10.5s remote control ID, refer to the
Remote Control Setup Sub-menu section on page 87.
The default ID for both the DTR-10.5 and remote con-
troller is 1.
Changing the Remote Controllers
Control ID
1
Hold down the remote controllers [Cus-
tom] button for more than three seconds.
The remote controller enters Custom mode.
2
Roll the scroll wheel to select SETUP
menu, and then press the scroll wheel.
3
Roll the scroll wheel to select ID menu,
and then press the scroll wheel.
4
Roll the scroll wheel to select an
ID1 (default), 2, or 3and then
press the scroll wheel.
Select the same ID as that set on the
DTR-10.5.

Table of Contents

Other manuals for Integra DTR-10.5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Integra DTR-10.5 and is the answer not in the manual?

Integra DTR-10.5 Specifications

Amplifier Specifications IconAmplifier Specifications
amplifier power output at 6 ohms200 W per channel
amplifier power output at 8 ohms150 W per channel
dynamic power output at 3 ohms2 x 340 W
dynamic power output at 4 ohms2 x 260 W
dynamic power output at 8 ohms2 x 175 W
frequency response5 Hz to 100 kHz
signal-to-noise ratio110 dB
total harmonic distortion0.08%
damping factor60 at 8 ohms
Input and Output Specifications IconInput and Output Specifications
line input sensitivity and impedance200 mV, 50 k ohms
multi-channel input sensitivity and impedance200 mV, 50 k ohms
subwoofer input sensitivity and impedance36 mV, 50 k ohms
rec out level and impedance200 mV, 470 ohms
pre out level and impedance1 V, 470 ohms
zone 2/3 line output level and impedance100 mV, 470 ohms
Radio Specifications IconRadio Specifications
AM tuning range530–1, 710 kHz
AM usable sensitivity30 µV
FM tuning range87.5–108.0 MHz
FM usable sensitivity, stereo17.2 dBf, 2.0 µV (75 ohms IHF)
Phono and Tone Control IconPhono and Tone Control
phono input sensitivity2.5 mV, 50 k ohms
phono overload70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio80 dB
bass control±12 dB at 50 Hz
mid range control±12 dB at 1, 000 Hz
treble control±12 dB at 20, 000 Hz
General Specifications IconGeneral Specifications
power supplyAC 120 V, 60 Hz
power consumption13.0 A
dimensions435 x 175 x 429 mm
weight32.1 kg
