Integra DTR-10.5 User Manual

46
Connecting AV Components —Continued
Connection example when the source selection is performed on the DTR-10.5
HDMI
IN
HDMI
OUT
HDMI
OUT
RS 232
IR IN
+
12 V DC PWR SUPPLY
MAIN
GND
ZONE
3
ZONE 2
20mA MAX.
12 V
TRIGGER
OUT
E
MODEL NO. DTR
-
10.5
GND
C
D
E
B
A
12 V
TRIGGER OUT
100mA MAX.
100mA MAX.
100mA MAX.
TOTAL
100mA MAX.
200mA MAX.
UPA
AC
INLET
E
)
SURR L
AC 230-240V 50Hz
SWITCHED 100W MAX.
AC OUTLET
SPEA-
KERS A
SPEA-
KERS B
IN 1
IN 2
HDMI
Y
P
B
P R
E
NT
Y
P
B
P R
ANTENNA
FM
75
O
L
OUT
J
K
AM
OUT
Y
P
B
P R
Y
P
B
P R
COMPONENT VIDEO
IN
(
HD/ BNC
)
RS 232
IR IN
+
12 V DC PWR SUPPLY
MAIN
GND
ZONE
3
ZONE 2
20mA MAX.
12 V
TRIGGER
OUT
E
MODEL NO. DTR
-
10.5
GND
C
D
E
B
A
12 V
TRIGGER OUT
100mA MAX.
100mA MAX.
100mA MAX.
TOTAL
100mA MAX.
200mA MAX.
A
AC
INLET
SURR L
AC 230-240V 50Hz
SWITCHED 100W MAX.
AC OUTLET
SPEA-
KERS A
SPEA-
KERS B
IN 1
IN 2
HDMI
ANTENNA
FM
75
L
OUT
K
AM
OUT
Y
P
B
P R
Y
P
B
P R
O
NENT VIDEO
IN
HDMI
IN
HDMI
IN
HDMI
OUT
Before making a connection, read the
DVD instruction manual thoroughly.
Connection example for higher video quality
When connecting an AV component equipped with the HDMI input terminal, you can use the connecting layout shown below.
Before making a connection, read the instruction manual of the connected device thoroughly.
DVD Player with HDMI
INPUT and OUTPUT
TV or Projector
DTR-10.5
TV or Projector
DVD Player with HDMI OUTPUT
Set Top Box with HDMI OUTPUT
DTR-10.5
Tips:
To enable HDMI audio output of the
DTR-10.5 from the TV speakers,
enable HDMI Out according to
“HDMI Out” on page 92.

Integra DTR-10.5 Specifications

Amplifier Specifications

amplifier power output at 6 ohms	200 W per channel
amplifier power output at 8 ohms	150 W per channel
dynamic power output at 3 ohms	2 x 340 W
dynamic power output at 4 ohms	2 x 260 W
dynamic power output at 8 ohms	2 x 175 W
frequency response	5 Hz to 100 kHz
signal-to-noise ratio	110 dB
total harmonic distortion	0.08%
damping factor	60 at 8 ohms

Input and Output Specifications

line input sensitivity and impedance	200 mV, 50 k ohms
multi-channel input sensitivity and impedance	200 mV, 50 k ohms
subwoofer input sensitivity and impedance	36 mV, 50 k ohms
rec out level and impedance	200 mV, 470 ohms
pre out level and impedance	1 V, 470 ohms
zone 2/3 line output level and impedance	100 mV, 470 ohms

Radio Specifications

AM tuning range	530–1, 710 kHz
AM usable sensitivity	30 µV
FM tuning range	87.5–108.0 MHz
FM usable sensitivity, stereo	17.2 dBf, 2.0 µV (75 ohms IHF)

Phono and Tone Control

phono input sensitivity	2.5 mV, 50 k ohms
phono overload	70 mV RMS at 1 kHz, 0.5% THD
RIAA deviation	20 Hz to 20 kHz: ±0.8 dB
phono signal-to-noise ratio	80 dB
bass control	±12 dB at 50 Hz
mid range control	±12 dB at 1, 000 Hz
treble control	±12 dB at 20, 000 Hz

General Specifications

power supply	AC 120 V, 60 Hz
power consumption	13.0 A
dimensions	435 x 175 x 429 mm
weight	32.1 kg
