Intel Agilex Series

Command Code
(Hex)
Command
Length
(14)
Response
Length
(14)
Description
• Bit [31:28]: Index of the firmware or decision
firmware copy that was used the most recently.
Possible values are 0, 1, 2, and 3.
• Bit [27:24]: Reserved
• Bit [23:16]: Value is '0'
Available in Intel Quartus Prime software version 21.3 or
later, the Quartus version displays:
• Bit [31:28]: Index of the firmware or decision
firmware copy that was used the most recently.
Possible values are 0, 1, 2, and 3.
• Bit [27:24]: Reserved
• Bit [23:16]: Major Quartus release number
• Bit [15:8]: Minor Quartus release number
• Bit [7:0]: Quartus update number
For example, in Intel Quartus Prime software version
21.3.1, the following values represent the major and
minor Quartus release numbers, and the Quartus update
number:
• Bit [23:16] = 8'd21 = 8'h15
• Bit [15:8] = 8'd3 = 8'h3
• Bit [7:0] = 8'd1 = 8'h1
2 Pin status •
Bit [31]: Current nSTATUS output value (active low)
•
Bit [30]: Detected nCONFIG input value (active low)
• Bit [29:3]: Reserved
•
Bit [2:0]: The MSEL value at power up
3 Soft function status Contains the value of each of the soft functions, even if
you have not assigned the function to an SDM pin.
• Bit [31:6]: Reserved
•
Bit [5]: HPS_WARMRESET
•
Bit [4]: HPS_COLDRESET
•
Bit [3]: SEU_ERROR
•
Bit [2]: CVP_DONE
•
Bit [1]: INIT_DONE
•
Bit [0]: CONF_DONE
continued...
(14)
This number does not include the command or response header.
