B.2. BIOS POST Progress Codes
Table 55 provides a list of all POST progress codes.
Table 55. POST progress codes
Post Code
(Hex)
Upper Nibble
Lower Nibble
Description
8h
4h
2h
1h
8h
4h
2h
1h
SEC Phase
01
0
0
0
0
0
0
0
1
First POST code after CPU reset
02
0
0
0
0
0
0
1
0
Microcode load begin
03
0
0
0
0
0
0
1
1
CRAM initialization begin
04
0
0
0
0
0
1
0
0
PEI Cache When Disabled
05
0
0
0
0
0
1
0
1
SEC Core At Power On Begin.
06
0
0
0
0
0
1
1
0
Early CPU initialization during SEC Phase.
KTI RC (Fully leverage without platform change)
A1
1
0
1
0
0
0
0
1
Collect info such as SBSP, boot mode, reset type, etc.
A3
1
0
1
0
0
0
1
1
Setup minimum path between SBSP and other sockets
A6
1
0
1
0
0
1
1
0
Sync up with PBSPs
A7
1
0
1
0
0
1
1
1
Topology discovery and route calculation
A8
1
0
1
0
1
0
0
0
Program final route
A9
1
0
1
0
1
0
0
1
Program final IO SAD setting
AA
1
0
1
0
1
0
1
0
Protocol layer and other uncore settings
AB
1
0
1
0
1
0
1
1
Transition links to full speed operation
AE
1
0
1
0
1
1
1
0
Coherency settings
AF
1
0
1
0
1
1
1
1
KTI initialization done
PEI Phase
10
0
0
0
1
0
0
0
0
PEI Core
11
0
0
0
1
0
0
0
1
CPU PEIM
15
0
0
0
1
0
1
0
1
Platform Type Init
19
0
0
0
1
1
0
0
1
Platform PEIM Init
31
0
0
1
1
0
0
0
1
Memory Installed
32
0
0
1
1
0
0
1
0
CPU PEIM (CPU Init)
33
0
0
1
1
0
0
1
1
CPU PEIM (Cache Init)
34
0
0
1
1
0
1
0
0
CPU BSP Select
35
0
0
1
1
0
1
0
1
CPU AP Init
36
0
0
1
1
0
1
1
0
CPU SMM Init
4F
0
1
0
0
1
1
1
1
DXE IPL started
DXE Phase
60
0
1
1
0
0
0
0
0
DXE Core started
62
0
1
1
0
0
0
1
0
DXE Setup Init
68
0
1
1
0
1
0
0
0
DXE PCI Host Bridge Init
69
0
1
1
0
1
0
0
1
DXE NB Init
6A
0
1
1
0
1
0
1
0
DXE NB SMM Init
70
0
1
1
1
0
0
0
0
DXE SB Init
71
0
1
1
1
0
0
0
1
DXE SB SMM Init
72
0
1
1
1
0
0
1
0
DXE SB devices Init
78
0
1
1
1
1
0
0
0
DXE ACPI Init
79
0
1
1
1
1
0
0
1
DXE CSM Init

Intel S2600WF Specifications

General

Memory Slots	16 DIMM slots
Chipset	Intel C621
Memory Support	DDR4 ECC RDIMM/LRDIMM
Expansion Slots	Up to 6 PCIe 3.0 slots
Storage Options	SATA, SAS
SATA Ports	Up to 10 SATA ports
CPU Socket Type	Socket P (LGA 3647)
