Intel® Server Board S2600WF Product Family Technical Product Specification
135
Table 59. Volatile and non-volatile components
Component Type
Size
Board Location
User Data
Name
Non-volatile
64 MB
U3D1
No(BIOS)
BIOS Flash
Non-volatile
64 MB
U1D1
NO(FW)
BMC Flash
Non-Volatile
4 Mbit
U5M1
No
10 GB NIC EEPROM (S2600WF)
Non-volatile
N/A
U1E3
No
CPLD
Volatile
512 MB
U1D2
No
BMC firmware SDRAM
None-volatile
8 GB
U8N1
No
BMC eMMC
Note: Table 59
does not identify volatile and non-volatile memory components for devices which may be
installed onto or may be used with the server board. These may include: system boards used inside a server
system, processors, memory, storage devices, or add-in cards.
