Intel® Server Board S2600WF Product Family Technical Product Specification
137
Table 60. Intel® Server System R1000WF product family feature set
Intel® Server Board S2600WF product family
Maximum Supported Processor
Thermal Design Power (TDP)
Up to 165 Watts
o Front and back
• RJ-45 serial port A connector on back panel
• Dual RJ-45 network interface connectors (S2600WFT-based systems only)
• Dedicated RJ-45 server management port on back panel
• (3) – USB 3.0 connectors on back panel
•
(2) – USB 3.0 connectors on front panel (non-storage system configurations only)
Internal I/O
Connectors/Headers
• (1) – Type-A USB 2.0 connector
•
(1) – DH-10 serial port B connector
• (6) – managed 40 mm dual rotor system fans
•
One power supply fan for each installed power supply module
Support for two riser cards:
• Riser #1 – PCIe* 3.0 x24
• Riser #2 – PCIe* 3.0 x24
With two riser cards installed, up to two possible add-in cards can be supported (one x16
PCIe* 3.0 add-in card slot per riser card):
•
(2) full height/half-length add-in cards via Risers #1 and #2
The server system can have up to two power supply modules installed, providing support for
the following power configurations: 1+0, 1+1 redundant power, and 2+0 combined power.
(2) power supply options:
• AC 1100W Platinum
•
• R1304WFxxx – 4 x 3.5” hot swap drive bays + SAS/SATA backplane
• R1208WFxxx – 8 x 2.5” hot swap drive bays + SAS/SATA/NVMe* combo backplane
Accessory Options
• AXXELVRAIL – Enhanced value rack mount rail kit – 424 mm max travel length
• A1UFULLRAIL – Tool-less rack mount rail kit with CMA support – 780 mm max travel length
• A1USHRTRAIL – Tool-less rack mount rail kit – 780 mm max travel length (no CMA support)
• AXX2POSTBRCKT – Two post fixed mount bracket kit
• AXX1U2UCMA2– Cable management arm (supported with AXXFULLRAIL only)
