Intel® Server Board S2600WF Product Family Technical Product Specification
133
C.1. POST Error Beep Codes
Table 57 lists the POST error beep codes. Prior to system video initialization, the BIOS uses these beep
codes to inform users on error conditions. The beep code is followed by a user-visible code on the POST
progress LEDs.
Table 57. POST error beep codes
Beeps
Error Message
POST Progress Code
Description
1 short USB device action N/A
Short beep sounded whenever USB device is discovered in POST,
or inserted or removed during runtime.
1 long
Intel® TXT security
violation
AE, AF
System halted because Intel® Trusted Execution Technology
detected a potential violation of system security.
3 short Memory error Multiple
System halted because a fatal error related to the memory was
detected.
3 long
and 1
short
CPU mismatch error E5, E6
System halted because a fatal error related to the CPU
family/core/cache mismatch was detected.
2 short
BIOS recovery
started
N/A BIOS recovery boot has been initiated.
4 short BIOS recovery failed N/A
BIOS recovery has failed. This typically happens so quickly after
recovery is initiated that it sounds like a 2-4 beep code.
The integrated BMC may generate beep codes upon detection of failure conditions. Beep codes are sounded
each time the problem is discovered, such as on each power-up attempt, but are not sounded continuously.
Codes that are common across all Intel server boards and systems that use same generation chipset are
listed in Table 58. Each digit in the code is represented by a sequence of beeps whose count is equal to the
digit.
Table 58. Integrated BMC beep codes
Code
Reason for Beep
Associated Sensors
1-5-1-2
VR Watchdog Timer sensor assertion
VR Watchdog Timer
1-5-1-4
The system does not power on or unexpectedly power off and a
power supply unit (PSU) is present that is an incompatible model
with one or more other PSUs in the system
PS Status
1-5-2-1
No CPUs installed or first CPU socket is empty
CPU Missing Sensor
1-5-2-2
CPU CAT Error (IERR) assertion
CPU ERR2 Timeout Sensor
1-5-2-3
CPU ERR2 timeout assertion
CPU ERR2 Timeout Sensor
1-5-2-4
CPU Icc max Mismatch
CPU Icc max Mismatch Sensor
1-5-2-5
CPU population error
CPU 0 Status Sensor
1-5-4-2
Power fault: DC power is unexpectedly lost (power good dropout).
Power unit – power unit failure offset
1-5-4-4
Power control fault (power good assertion timeout).
Power unit – soft power control failure offset
