Server Board Installation and Upgrades 31
Minimum Hardware Requirements
To avoid integration difficulties and possible board damage, your system must meet the following
minimum requirements. For a list of qualified memory and chassis components see:
http://support.intel.com/support/motherboards/server/SE7501BR2
Processor
Minimum of one Intel Xeon processor with 512K cache support. For a complete list of supported
processors, see:
http://support.intel.com/support/motherboards/server/SE7501BR2
Memory
Minimum of two 128 MB ECC, DDR266 compliant registered DIMMs on 184-pin gold DIMMs.
Power Supply
Minimum of 450 W. Your supply must provide a minimum of 1.2 A of 5 V standby current or the
board will not boot.
Installation Notes
Installation Process Quick Reference
Step Where the information is located
Remove the access cover Your chassis manual
Install the I/O shield Page 32
Install the standoffs Page 34
Install the rubber bumper Page 35
Install the server board Page 36
Connect cables to the server board Page 37. Refer also to your chassis
manual
Install the processor and processor wind tunnel in the Intel® Server
Chassis SC5200 base chassis or in a reference chassis
Page 40
Install the processor in the Intel® Server Chassis SC5200 with Hot
Swap Redundant Power
Page 47
Install memory Page 52
