Configuration Software and Utilities 79
To use the Server
Configuration utility to
Description of procedure
Page
Configure the server for
remote LAN
management
Enable a connection to the server from a workstation on the LAN to
allow remote management functions, such as powering the server on or
off, or running diagnostic utilities.
87
Configure for Remote
Serial / Modem
management
Enable a connection to the server from a serial or Modem connection to
allow remote management functions, such as powering the server on or
off, or running diagnostic utilities.
88
Configure for Serial /
Modem alerting
Configure the server to send a telephone page in the event that a
hardware or firmware error occurs at the server.
91
Configure for LAN
alerting
Configure the server to send a notification message to a workstation
segment of the network in the event that a hardware or firmware error
occurs at the server.
92
Run the FRU/SDR Load
Utility
Use to update the Field Replaceable Unit (FRU) and Sensor Data
Record (SDR) flash components.
NOTE: You must run the FRU/SDR Load utility whenever the BMC is
updated or if you change your processors.
95
Configure an Asset Tag Assign an identification number or serial number to the server. 98
Create / modify the
service partition
If a service partition does not already exist, create one. If a service
partition has been created earlier, update it.
99
Create System or Utility
/ Device Diskettes
Create diskettes by operating system, utility, or device driver. 98
Save / load
configuration data
Save the configuration data to a file. Use this saved file to configure
other servers identically.
100
Direct Platform Control (DPC) Console
Direct Platform Control (DPC) Console is part of Intel Server Management. Direct Platform
Control is a server management application that supports remote system management via LAN, or
an RS-232 serial connection to the server Serial B port over a modem or a direct serial cable. The
Direct Platform Control Console provides the ability for remote management of Intel servers via
modem or LAN with a capability to run DOS-based programs.
DPC console runs on a client workstation and is independent of the server operating system. It
communicates with a server by:
• Accessing the server management capabilities of the on-board NIC
• A Windows
†
2000 compatible modem
• An RS-232 connection to the server’s Serial B port
