POST and the BIOS Setup Utility 65
Table 16. Memory Configuration Submenu
Feature
Choices or
Display Only
Description
Extended Memory
Test
1 MB
1 KB
Every Location
Disabled
Selects the size of step to use during the extended RAM tests.
When disabled is selected, extended memory tests are not run.
The Every Location selection will increase the boot time.
Memory Bank #1
(DIMM 1A, 1B)
Installed
Not Installed
Disabled
Displays the current status of Memory Bank 1. Disabled indicates
that a DIMM in the bank has failed and the entire bank has been
disabled.
Memory Bank #2
(DIMM 2A, 2B)
Installed
Not Installed
Disabled
Displays the current status of Memory Bank 2. Disabled indicates
that a DIMM in the bank has failed and the entire bank has been
disabled.
Memory Retest Enabled
Disabled
When enabled is selected, the BIOS retests all memory on the
next boot. This option automatically reverts to disabled upon
booting.
Table 17. Advanced Chipset Control Submenu
Feature
Choices or
Display Only
Description
Wake On Ring Enabled
Disabled
Controls legacy wake-up source
Wake On LAN Enabled
Disabled
Controls legacy wake-up source
Wake On PME Enabled
Disabled
Controls legacy wake-up source
Wake On RTC Alarm Enabled
Disabled
Controls legacy wake-up source
