60 Intel Server Board SE7501BR2 Product Guide
Table 7. On-Screen Options
When you see this: What it means:
On screen, an option is shown but you
cannot select it or move to that field.
You cannot change or configure the option in that menu screen.
Either the option is auto-configured or auto-detected, or you must
use a different Setup screen.
On screen, the phrase Press Enter
appears next to the option.
Press <Enter> to display a submenu that is either a separate full
screen menu or a popup menu with one or more choices.
Menu Selection Bar
The Menu Selection Bar is located at the top of the screen and displays the major menu selections
available to the user.
Table 8. Menu Selection Bar
Main Advanced Security Server Boot Exit
Allocates
resources for
hardware
components
Configures
advanced
features
available
through the
chipset
Sets and clears
passwords and
security features
Information on
Vendor,
Processor,
Memory,
Peripherals, and
BIOS
Selects boot
options and
power supply
controls
Saves or
discards
changes to
Setup program
options
Main Menu
You can make the following selections from the Main Menu. Use the submenus for other
selections.
Table 9. Main Menu Selections
Feature Choices Description
System Time HH:MM:SS
Sets the system time (hour, minutes, seconds, on
24 hour clock).
System Date MM/DD/YYYY Sets the system date (month, day, year).
Floppy A
Not installed
1.44/1.25 MB, 3.5-inch
2.88 MB
Selects the diskette type.
Hard Disk Pre-delay
Disabled
3 seconds
6 seconds
9 seconds
12 seconds
15 seconds
21 seconds
30 seconds
Provides time to allow drives that spin-up slower to
become ready.
Primary IDE Master <Enter> Displays the IDE device selection. Enters submenu.
continued
