38 Intel Server Board SE7501BR2 Product Guide
Cable Routing
To ensure proper airflow within the chassis, follow the cable routing guidelines below.
SCSI Cables
SCSI cables that connect to devices in the lower device bays should be routed around the fan
housing and ducts as shown below.
Floppy Drive Cable
Route the floppy drive cable as shown.
OM14641
Route cables here
Figure 10. Routing the SCSI and Floppy Drive Cable
