POST and the BIOS Setup Utility 71
Boot Menu
You can make the following selections from the Boot Menu.
Table 24. Boot Menu
Boot Priority Device Description
Boot Device Priority <Enter> Enters submenu
Hard Disk Drives <Enter> Enters submenu
Removable Devices <Enter> Enters submenu
ATAPI CD-ROM Drives <Enter> Enters submenu
Table 25. Boot Device Priority Submenu
Boot Priority Device Description
1 Removable
Devices
The server attempts to boot from the diskette drive or remove
able device such as the LS-120.
2 Hard Drive The server attempts to boot from a hard drive device.
3 ATAPI
CD-ROM
Drive
The server attempts to boot from an ATAPI CD-ROM drive
containing bootable media.
4 Any SCSI
CD-ROM
Drive
The server attempts to boot from a SCSI CD-ROM drive
containing bootable media. This option is available only if a
bootable CD-ROM is present. The device needs to be
controlled by a BIOS Boot Specification-compliant SCSI
option ROM.
5 PXE UNDI The system attempts to boot from the network. This entry will
appear if there is a network device in the system that is
controlled by a PXE-compliant option ROM.
Table 26. Hard Drive Selection Submenu
Feature Choices Description
Device list:
Drive #1 (or the drive
string)
Other bootable cards
Each drive with a PnP
header
Plus (+) key
Minus (-) key
Select the boot drive with the up and down arrows to highlight
the device.
Use the plus (+) key to move the selected device up in the list.
Use the minus (-) key to move the device down in the list.
“Other bootable cards” indicates boot devices that are not
reported to the system BIOS through the BIOS boot
specification mechanism. These devices may or may not be
bootable.
