v130 – Marine Satellite Communication System

104

Backup & Restore

No. Item Description

Backup

Restore

Enter Backup & Restore page. (Setup mode is required)

Target

Backup antenna information to ACU/PC or Restore antenna by

using the saved information ACU/PC.

Backup Backup antenna information.

Restore Restore antenna information.

1 2
