Technical Specication
v110 v130
Approvals
CE – conforms to EU Directive 89/336/EEC
FCC – veried to CFR47: Part 15
Dimensions
Satellite Antenna Unit
147.4 x 152.2 cm
(58” x 59.9”)
165.2 x 168.9 cm
(65” x 66.5”)
Antenna Dish Diameter 105 cm (41.3”) 125 cm (49.2”)
Antenna Control Unit 43.1 x 38.1 x 4.4 cm (17” x 15” x 1.7”)
Weight
Satellite Antenna Unit 139.5 kg (307.5 lbs) 149.7 kg (337 lbs)
Antenna Control Unit 5.2 kg (11.5 lbs)
Antenna System Performance
TX Frequency 14.0 ~ 14.5 GHz Ku-band
TX Gain 41.7 dBi 43.2 dBi
RX Frequency 10.95 ~ 12.75 GHz Ku-band
RX Gain 39.8 dBi 42.1 dBi
Polarized Feed Cross-pol or Co-pol
LNB pol Control Automatic LNB pol-angle Control
Azimuth Range Unlimited
Elevation Range -15° ~ +120° -20° ~ +120°
Cross-level Range ± 37°
Stabilization Accuracy 0.2° peak mis-pointing @ max ship motion condition
Max Ship’s Motion ±25° roll, ±15° pitch, ±8° yaw @ 6 sec
Turning Rate Up to 12°/ sec & 5°/ sec
2
BUC 4W, 8W (optional)
Rack Mount Antenna Control Unit
Display 2 Line 40 Character Graphic VFD Module
Serial Interface RS232C (19200 bps 8, N, 1)
Modem Interface Ethernet port / RS232C / I/O ports
Remote Access TCP / IP
Input Power
100~240 V AC, 50~60 Hz
(Max 350W including 8W BUC Power)
Gyrocompass Interface NMEA / Synchro
