Upgrade Steps

1. Click on “Browse” button to select the E2S rmware le (.bin) that you wish to upgrade.

2. Click on “Start Update” button to update the E2S rmware. Wait until the page is loaded.

3. It’ll inform you that the rmware is being uploaded.

4. It takes around 30 seconds to complete the rmware upgrade. Please reconnect

the web page after upgrade.

Firmware

uploaded

message

System disconnection
