Intellian v130 User Manual

v130 – Marine Satellite Communication System
110
Serial Setting [1]
No. Item Description
1
Serial Setting Congure Serial port [1] and Serial port [2]
2
Serial Port [1]
Serial Port [1] is to communicate with an external modem via
Ethernet. Follow the instruction below to congure Serial port
[1] and press Submit button. Go to “Save & Reboot” page
and press Save & Reboot button to validate the changes.
- Operation mode: TCP Server
- Local socket port: 4001
- Baud Rate: 9600 bps
- Data Bit: 8 Bit
- Stop Bit: 1 Bit
- Parity: None
- Flow Control: None
The data communication between the modem and the PC
may disconnect while setting these parameters.
3
[1][2] Select to congure Serial port [1] or Serial port [2]
1
2
3
