6. Set MODEM PORT* and MODEM PROTOCOL*
MODEM PORT is to select a proper data communication port on the ACU to interface with
the satellite modem. MODEM PROTOCOL is to select a proper communication protocol on
the ACU to interface with the satellite modem.
13V + 0KHZ 18V+0KHZ
10000MHZ 11300MHZ
13V +22 KHZ 18V+2 2KHZ
10000MHZ 09750MHZ
7. Set the LNB local oscillator frequency for each voltage power. (13V +0 kHz, 18V +0 kHz,
13V +22 kHz, 18V +22 kHz)
Press LEFT and RIGHT arrow keys until the desired character is underscored (selected).
Press UP and DOWN arrow keys to increase or decrease the value. Or press NUMBER keys
to set the desired value directly.
MODEM PORT*
RS232
RS422
ETHERNET
Modem port & Modem
protocol
LNB local frequency
GYRO TYPE*
NO DEVICE
NMEA / SYNCHRO
GROUND TEST
Gyro search mode
MODEM PROTOCOL*
I/O CONSOLE
OPEN AMIP
SERIAL GPS
ROSS
Setting of Heading Device
Existence of Heading Data No
Device
NMEA/
Synchro
Ground Test
With Heading Data
Search 1 Search 3 Search 3
Without Heading Data
Search 1 Search 1 Search 3
MODEM PORT MODEM PROTOCOL
RS232 SERIAL GPS
