Intellian v130 User Manual

57
OPERATING THE ACU
Antenna Diagnostic Test
Refer to the diagnosis codes for the test results.
Single diagnostic
test result
Full diagnostic test
Full diagnostic
test result
Diagnosis menu
Antenna menu
Setup mode
SETUP MODE ?
YES NO
1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.
+ANTENNA +SATELLITE
+SYSTEM +INSTALLATION
2. Press OK key to enter ANTENNA menu.
+BLOCK ZONE +DIAGNOS IS
3. Press arrow keys to move cursor to DIAGNOSIS menu and press OK key to enter it.
DIAGNOSIS COMMUNICATION
FULL TEST READY
4. Press UP and DOWN arrow keys to select a full diagnostic test or single diagnostic test
and press OK key to execute the selected diagnostic test.
Menus for DIAGNOSIS are FULL TEST and CODE 101 ~ CODE 116.
DIAGNOSIS FULL TESTING
FULL TEST
- -
5. A full diagnostic is successfully completed.
DIAGNOSIS COMMUNICATION
CODE 101 RESULT : PASSED
6. A single diagnostic test is successfully completed.
