v130 – Marine Satellite Communication System

100

Block Zone Setting

No. Item Description

Block Zone

Setting

Up to 5 block zones are allowed to be programmed.

Block Zone

This is the clockwise of the two points. AZ. START is where the rela-

tive azimuth starts and AZ. END is where the relative azimuth ends

(Range: 0 - 360°). EL. Limit is where the elevation starts (Range 0

- 90°).
