v130 – Marine Satellite Communication System

Set LNB Local Oscillator Frequency

System Settings

System menu

Set local frequency menu

LNB info

Setup mode

Save

SETUP MODE ?

YES NO

1. Press LEFT arrow key to move cursor to YES and press OK key to enter SETUP mode.

+ANTENNA +SATELLITE

+SYSTEM +INSTALLATION

2. Press DOWN arrow key to move cursor to SYSTEM and press OK key to enter it.

+SET LOCAL +SET LOCATION

+MODEM PORT +BACKUP& RESTORE

3. Press OK key to enter SET LOCAL menu to set the LNB local frequency.

13V + 0KHZ 18V + 0KHZ

10000MHZ 11300MHZ

13V + 22KHZ 18V + 22KHZ

10750MHZ

09750MHZ

4. Set LNB local oscillator frequency for each correspondent voltage power.

(13V +0 kHz, 18V +0 kHz, 13V +22 kHz, 18V +22 kHz)

Press RETURN key and press LEFT and RIGHT arrow keys to select the parameter you wish

to edit. Press OK key to edit parameter. Or press RETURN key again to return to the main

display.

LNB LOCAL: The selectable LNB frequencies are depended on the installed LNB type.

SAVE ?

YES NO

5. Press LEFT arrow key to move cursor to YES and press OK key to save current settings.

Or move cursor to NO and press OK key to abort and return to the main display.

Intellian v130 User Manual
