NBD F:1247000 BW:1000 SIG:301
004.53E 5 2.22N HDG:090.0 L:10000 Fn
5. NBD, GPS and ship’s heading information are shown.
- NBD (Narrow Band Detection) IF tracking frequency: 1247000 kHz
- Detected Band Width: 1000 kHz
- SIG (Signal Level ): 301 (When NBD mode for tracking signal is chosen)
- W (West)/E (East) Longitude: 4.53º E
- N (North)/S (South) Latitude: 52.22º N
- HDG (Ship’s Heading): 90º
- LNB local oscillator (LO) frequency: 10000 MHz
[PWR] ANT: 26.4V LNB: 13V + 0KHZ
ACU: 27.1V [POL] TX:V RX:H
6. Press RIGHT arrow key to display the current operation voltage for antenna, ACU and
LNB. POL indicates the TX polarity (VERTICAL) and RX polarity (HORIZONTAL).
V1-110-23H ANT. SERIAL 1.00
VP-T201 ACU SERIAL 1.00(1.00)
7. Press RIGHT arrow key to display the below information.
- Antenna part number, antenna serial number and PCU rmware version.
- ACU part number, ACU serial number, ACU rmware version and Library version.
Press RETURN Key to return to the rst page of the antenna current status.
8. Press RIGHT arrow key to display the real-time diagnostic result.
The real-time diagnostic code will be displayed automatically if there is any error found
during the system operation. However, this page will not be displayed if there is no error
message.
9. Press FUNCTION key to erase diagnostic error message.
Tracking & Heading
information
Power status
Antenna & ACU
versions
[DIAGNOSIS] SENSOR BOX
CODE10 9 RESULTS : FAI LED FN
ERASE DIAGNO SIS ERRO R LOG ?
YES NO
Real-time
diagnostic
result
Erase
Error message
To Next Page
