SEARCH1 138.0E TELST_18 SIG:301 VL
AZ:292.7( 202.7) EL: 48. 3 SK: -72.0
1. The antenna is searching for the target satellite.
TRACKING 138.0E TELST_18 SIG:301 VL
AZ:292.7( 202.7) EL: 48. 3 SK: -72.0 Fn
2. The antenna has locked onto the target satellite.
Current IF signal level (SIG/AGC) is displayed. SIG will be displayed when NBD (Narrow band
detection) mode for TRACKING SIGNAL is chosen to be used and AGC will be displayed
when DVB mode of TRACKING SIGNAL is chosen to be used.
The symbol “•” will be only displayed when the satellite signal is strong enough to locked
onto. [VL] indicates the LNB's local frequency corresponding to 13V is in use for the signal
reception.
VL: 13V + 0 kHz, HL: 18V + 0 kHz, VH: 13V + 22 kHz, HH: 18V + 22 kHz
Press the UP or DOWN arrow key to increase or decrease the LNB skew angle.
True azimuth [292.7] position of the antenna is the sum of ships heading 090.0 [HDG] and
antenna relative [202.7].
SAVE CURRENT SAT INFO ?
YES NO
3. Press FUNCTION key to save current satellite information or abort and return to the main
display. "Fn" will be displayed only if the antenna is in tracking mode.
NOTE: However, if the "GYRO TYPE" is set to "NONE" or "NMEA" but without
receiving a proper input signal, "---.-" will be displayed at "True Azimuth"
Monitoring Antenna Current Status
When the ACU power is on, it displays the status of the antenna. The current status
of the antenna is displayed as shown below.
Current search status
Current tracking status
Save current satellite info
TRACKING 138.0E TELST_18 SIG:301 VL
AZ:---.-( 202.7) EL: 48. 3 SK: -72.0 Fn
