115

REMOTE WEB ACCESS

Save & Reboot

Save & reboot page

No. Item Description

Save & Reboot

Save settings to the ACU and reboot or reboot the

system without saving.

Save & Reboot Save the modied settings and reboot the system.

Reboot without Saving

Reboot the system without saving the modied settings.
